APPLICATIONS:-

• CBR TESTING

INPUT:-

• LOAD CELL (STRAIN GAUGE ( 0 - 20 mV))
• LVDT (LINEAR POT)

SALIENT FEATURES:-

• LCD / LED DISPLAY/
• 10,000 TO 50,000 COUNTS
• LVDT COUNTS 0.01
• 2 UNIT CONVERSIONS
• AUTO CALIBRATION
• AUTO BREAKING AT MAXIMUM LOAD & SAMPLE BREAK
• 5 KEY'S KEYBOARD FOR EASY OPERATION

CABINET & DIMENSIONS:-

• PLASIC CABINET
• ALUMINIUM CABINET
• 185MM(W) X 90MM(H) X 165MM(D)
• 226 MM(W) X 88 MM(H) X 220 MM(D)

OPTIONAL FEATURES:-

• RS 232 SERIAL
• DATA LOGGING
• DOT MATRIX PRINTER
• SPEED THROUGH VFD
